H3C WAP662 Indoor Wi-Fi 6 Large Enterprises Access Point

Cash Price: ৳50,500.00 Regular Price:৳55,500.00
Availability: In Stock SKU: 6.53.250.3306
Quick Overview
Brand:
H3C
Model:
WAP662
  • Maximum Throughput: 6 Gbps
  • Wi-Fi Standard: Wi-Fi 6 (802.11ax)
  • Outdoor Range: 150 ~ 200 Meters
  • Security: WPA3, 802.1X, Enhanced Open
  • Power: PoE+ (802.3at), higher consumption
  • Management: H3C IMC (on-premises), Cloud, SDN
  • Application: Large Enterprises, High-Density, Public Venues

View More
Rating: (0 Reviews)

Payment Options
Share:
  • Support

    Saturday – Thursday: 09 AM - 06 PM.
  • Hotline

    0967 881 4452
  • Whatsapp

    +880170 999 8397
  • Payment

    Cash on Delivery | Card | Online Payment
  • Shipping Cost

    Inside Dhaka 250tk | Outside Dhaka 350tk
  • Warranty Policy

    Read More

Specification

Brand H3C
Model WAP662
Antenna Type Built-in omni-directional antenna
Antenna Gain 5GHz peak gain: 6dBi 2.4GHz peak gain: 6dBi Note: The equivalent antenna gain is 5dBi in 5GHz and 5dBi in 2.4GHz
Frequency Bands 2.400to2.4835GHzISM 5.150to5.250GHzU-NII-1 5.250to5.350GHzU-NII-2A 5.470to5.725GHzU-NII-2C 5.725to5.850GHzU-NII-3/ISM, Note: The available bands and channels are dependent on the configured regulatory domain (country)
Modulation Technology OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps
Modulation Mode 11b: DSSS: CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps 11a/g: OFDM: 64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps 11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM 11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM 11ax: MIMO-OFDM: BPSK, QPSK, 16QAM,
Maximum Transmit Power 5GHz: 26dBm 2.4GHz: 23dBm Note: Transmit power is multi-chain combined power, no antenna gain is included. The actual transmit power depends on local laws and regulations
PoE input 1 x 100/1000M/2.5G/5G Multigigabit Ethernet, 802.3at/af
PoE output 1 x 100/1000M Multigigabit Ethernet, 802.3af
Console port 1 × Management console port (RJ-45)
USB port 1(2.0) at 2.5W
Interface 1 x 100/1000M/2.5G/5G Multigigabit Ethernet, RJ-45, PoE input 1 x 100/1000M Multigigabit Ethernet, RJ-45, PoE output
Health Standards EN 50385:2017 EN IEC 62311:2020
Safety Standards IEC/EN 62368-1 GB 4943.1 SRRC
Protection Class IP42
Local Power Supply 54V DC
Overall Power Consumption 40W (including PSE and USB) 22.5W (excluding PSE and USB) Note: Power required at the power source equipment (PSE) will depend on the cable length and other environmental issues.
Dimensions (W × D × H) 215mm X 215mm X 45mm
Weight 0.94kg

Description

Buy H3C WA6622 New Generation 802.11ax Indoor Access Point Price in Bangladesh

The H3C WAP662 New Generation Access Point is a high-performance, enterprise-grade wireless access point (AP) that harnesses the power of Wi-Fi 6 (802.11ax) technology to meet the ever-growing demands for bandwidth, performance, and reliability in modern networks. Designed for medium to large-scale deployments in a variety of sectors, such as corporate offices, educational institutions, hospitals, hotels, and convention centers, the WAP662 offers enhanced network efficiency, increased client capacity, and improved security features. The H3C WAP662 is designed for indoor use. Its sleek and compact design, along with its mounting options (ceiling and wall), makes it suitable for indoor environments such as offices, schools, hospitals, hotels, and public venues. Additionally, its operating temperature range (0°C to 50°C) and lack of outdoor-specific features like weatherproofing indicate that it is intended for indoor deployment rather than outdoor use.

The H3C WAP662 is a high-performance wireless access point (AP) designed to provide reliable and secure wireless connectivity in enterprise environments. H3C WAP662 is a Wi-Fi 6(802.11ax)AP product independently developed by Xinhua Three Technology Co., Ltd. (H3C). The whole machine has four-frequency and the maximum turnover rate of the whole machine is 1.775Gbps. Wireless coverage needs.  Let’s dive into a comprehensive, detailed description of its key features,and deployment benefits.

Wi-Fi 6 Technology for Superior Performance: The H3C WAP662 is built on the 802.11ax (Wi-Fi 6) standard, which represents a significant leap forward in wireless networking. Unlike its predecessor (Wi-Fi 5 or 802.11ac), Wi-Fi 6 improves network efficiency, increases throughput per user, and enhances overall capacity. Here’s a breakdown of Wi-Fi 6 features that are central to the WAP662's performance:

  • Orthogonal Frequency Division Multiple Access (OFDMA): This feature enables the AP to divide a channel into smaller subchannels, allowing multiple clients to communicate simultaneously. This improves overall efficiency and reduces latency.OFDMA enables more efficient utilization of available bandwidth by dividing channels into smaller sub-channels, allowing multiple clients to communicate simultaneously. This minimizes latency and increases throughput, especially in high-density environments where many devices compete for bandwidth.
  • MU-MIMO (Multi-User Multiple-Input, Multiple-Output): The WAP662 can handle data streams for multiple users simultaneously, improving throughput in high-density environments. MU-MIMO allows the AP to communicate with multiple devices at once by using multiple data streams. With 4x4 MU-MIMO support, the WAP662 can serve several clients simultaneously, improving efficiency in congested networks.
  • 1024-QAM Modulation: The WAP662 supports 1024-QAM, which allows the transmission of more data in each packet. This results in higher data rates, enabling faster downloads and smoother video streaming experiences.
  • 160 MHz Channel Bandwidth: By using 160 MHz wide channels (compared to the typical 80 MHz channels in previous standards), the WAP662 can deliver higher throughput, especially beneficial for bandwidth-hungry applications like HD video conferencing, online gaming, and virtual reality.
  • Target Wake Time (TWT): This feature helps optimize power consumption by scheduling communication with devices at specific intervals. It is particularly useful for IoT (Internet of Things) devices, enabling them to remain in low-power sleep mode when not actively transmitting, which can significantly extend battery life.
  • High-performance Wi-Fi 6 support: The WAP662 is equipped with the latest Wi-Fi 6 technology, also known as 802.11ax, offering superior data rates, enhanced client capacity, and improved network efficiency compared to Wi-Fi 5 (802.11ac).
  • Dual-band capability: It operates on both the 2.4 GHz and 5 GHz bands, providing up to 4x capacity for connected devices.

Blazing Fast Speed and Capacity: The H3C WAP662 boasts dual-band support, allowing it to operate simultaneously on both the 2.4 GHz and 5 GHz frequencies. This dual-band operation enables higher overall throughput and helps mitigate interference, ensuring seamless connectivity for all connected devices.

  • Maximum Data Rate: The WAP662 offers a combined data rate of up to 6 Gbps across both bands. This is divided as:
  1. 4.8 Gbps on the 5 GHz band, which is ideal for high-speed activities such as HD video streaming, large file transfers, and low-latency applications.
  2. 1.2 Gbps on the 2.4 GHz band, which is great for legacy devices and applications that require less bandwidth.
  • 160 MHz Channel Bandwidth: This feature boosts the throughput, especially for bandwidth-hungry applications like video conferencing and large file transfers.
  • 4x4 MIMO Technology: Enhances spatial data streams, further improving performance and network efficiency.
  • Client Capacity: Thanks to Wi-Fi 6's enhancements in handling multiple devices, the WAP662 can efficiently manage more concurrent connections without degrading performance, making it suitable for high-density environments like auditoriums, stadiums, and conference halls.

Advanced Security and Encryption: Security is paramount in enterprise networks, and the H3C WAP662 is equipped with the latest in wireless encryption and protection mechanisms:

  • WPA3 (Wi-Fi Protected Access 3): This latest encryption protocol provides stronger data protection and improved password-based authentication, reducing the risk of brute-force attacks and securing sensitive data transmissions over the air.
  • Enhanced Open: This feature ensures that even in open Wi-Fi networks (without passwords), traffic is encrypted to prevent eavesdropping and unauthorized data access.
  • Guest Network and Captive Portal: The WAP662 supports guest access with customizable captive portals, allowing administrators to set up secure and segregated networks for visitors without compromising the security of the primary network.
  • 802.1X Authentication: This feature ensures that only authorized users can access the network, enhancing the overall security by validating each connection request.

Enterprise-Grade Features for Optimized Performance: The H3C WAP662 is packed with features that ensure top-tier performance in enterprise environments:

  • Seamless Roaming: The WAP662 supports fast and uninterrupted roaming between access points, ensuring smooth transitions for mobile users. As users move throughout the coverage area, the WAP662 supports fast, seamless roaming between access points. This is crucial in environments like large offices or campuses where users may need to move from one location to another without experiencing dropped connections or degraded performance.
  • Basic Service Set (BSS) Coloring: This feature is used to distinguish between overlapping networks that may be operating on the same channel. It reduces co-channel interference and improves the overall efficiency of the wireless network, especially in dense deployment scenarios.
  • QoS (Quality of Service): The WAP662 supports advanced QoS features, enabling network administrators to prioritize traffic for critical applications like VoIP (Voice over IP), video conferencing, and streaming, ensuring that these services remain uninterrupted, even in times of high network congestion.
  • Advanced security: Equipped with WPA3, the latest encryption standard, it ensures secure communications and protection against brute force attacks.
  • Captive portal support: Allows for user authentication via a web interface, commonly used for guest networks in enterprises.
  • Flexible deployment options: It can be deployed as a standalone access point or managed centrally through H3C’s Cloud Management Platform.
  • Target Wake Time (TWT): This feature reduces power consumption for devices by scheduling wake times, making it ideal for IoT devices.
  • BSS Coloring: Helps minimize interference by distinguishing between overlapping basic service sets (BSS) on the same frequency.

Design and Installation: The H3C WAP662 is designed with ease of deployment in mind:

  • Compact and Stylish Design: The WAP662 has a sleek and modern design, making it suitable for indoor deployment in various environments, such as offices, hotels, and educational institutions.The access point features a sleek, modern design that blends well into indoor environments, making it suitable for installation in offices, schools, hotels, and public areas without disrupting the aesthetic.
  • Easy installation: Designed for simplified installation, it comes with support for both wall and ceiling mounting options.
  • Mounting Options: The WAP662 supports both ceiling and wall mounting options, giving flexibility in installation based on the coverage needs and layout of the space.
  • Power over Ethernet (PoE): Powering the WAP662 through PoE simplifies deployment by eliminating the need for dedicated power outlets. Simplifying deployment, the WAP662 supports PoE+ (802.3at), allowing the AP to be powered through a single Ethernet cable, reducing the need for separate power outlets and making installation quicker and more cost-effective.

Centralized Management and Monitoring: The H3C WAP662 is designed to be easily managed, either as a standalone AP or as part of a larger network infrastructure:

  • Centralized Management with H3C IMC (Intelligent Management Center): For large-scale deployments, the WAP662 can be managed via H3C's IMC platform, allowing for centralized configuration, monitoring, and troubleshooting of multiple APs from a single interface. Administrators can quickly deploy new APs, adjust settings, and monitor network performance in real-time. It supports centralized management via H3C's Intelligent Management Center (IMC), enabling easy network configuration, monitoring, and troubleshooting.
  • Cloud-based Management: The WAP662 also supports cloud-based management through H3C’s cloud platform, enabling remote access to the AP’s settings and performance data, making it easy to manage distributed networks across multiple sites.  The access point can be controlled and monitored through H3C's cloud-based management platform, allowing for remote configuration and real-time analytics.
  • Software-Defined Networking (SDN) Support: The WAP662 is compatible with SDN, which allows for automated provisioning and simplified network operations. This integration with SDN controllers enables greater flexibility, scalability, and responsiveness in managing the network. The WAP662 is compatible with Software-Defined Networking (SDN), enabling automated provisioning and simplified network operations.

Environmental and Physical Specifications: The H3C WAP662 is built to withstand various environmental conditions typical of indoor enterprise environments:

  • Operating Temperature: 0°C to 50°C (32°F to 122°F), ensuring reliable operation in various climates.
  • Maximum Power Consumption: The WAP662 consumes a maximum of 25W, making it an energy-efficient solution for enterprise deployments.

Use Cases and Applications: The versatility of the H3C WAP662 makes it ideal for a wide range of applications:

  • Corporate Offices: Ensure fast, reliable connectivity for employees and visitors, with features like seamless roaming and advanced security.
  • Educational Institutions: Provide high-speed access for students and faculty across large campuses, with support for bandwidth-intensive applications like online learning platforms and video streaming.
  • Healthcare: Enable secure, uninterrupted connectivity for patient records, IoT devices, and medical equipment, while ensuring compliance with security regulations.
  • Hospitality: Deliver seamless, high-speed Wi-Fi to guests, with options for captive portal authentication and segregated guest networks.
  • High-density environments: Suitable for enterprise offices, educational campuses, large conference venues, and other areas with heavy network traffic.
  • IoT integration: With Wi-Fi 6 and TWT, it's well-suited for IoT device networks where power efficiency and bandwidth management are critical.

The H3C WAP662 is a cutting-edge access point leveraging Wi-Fi 6 technology to offer enhanced performance, greater device capacity, and improved security for modern enterprise environments. It is designed to meet the demands of high-density, mission-critical applications, ensuring reliable and scalable wireless connectivity. The H3C WAP662 New Generation Access Point is a state-of-the-art wireless access solution that brings the benefits of Wi-Fi 6 to enterprise environments. With its advanced features, high throughput, increased client capacity, robust security protocols, and ease of deployment, the WAP662 is perfectly suited for large-scale networks where performance, reliability, and scalability are paramount. Whether used in a corporate office, school, or public venue, the H3C WAP662 ensures that users have fast, secure, and uninterrupted access to the network, even in the most demanding environments.

What is the price of H3C WAP662 Indoor Wi-Fi 6 Large Enterprises Access Point in Bangladesh?

The latest price of H3C WAP662 Indoor Wi-Fi 6 Large Enterprises Access Point in Bangladesh is ৳50,500.00 . You can buy the H3C WAP662 Indoor Wi-Fi 6 Large Enterprises Access Point at best price from BME ONLINE SHOP, Bangladesh.
