Matica LCP9660 Laser Color Personalization System

Matica LCP9660 Laser Color Personalization System in Bangladesh

The Matica LCP9660 is a next-generation, high-security card personalization system designed for issuance of high-quality ID cards, driver licences, membership cards and other secure credentials. It integrates a high-resolution colour retransfer printing engine with an in-line laser engraving module to produce cards with both vivid full-colour images and laser-engraved security features in a single pass.

This system enables over-edge colour printing (via retransfer technique) at up to 600 × 600 dpi, combined with fibre-laser engraving (up to 1200 dpi) into the card body for a highly tamper-resistant result.  It is ideal for decentralised issuance models (e.g., branch networks or regional offices) where speed, flexibility and security matter.

In addition, the LCP9660 supports visual security elements such as invisible UV-colours, changeable laser images (CLI), multiple laser images (MLI) and the Matica Secure Protected Image (MSPI™) technology, which enables engraving of the black (K) component of a colour image beneath the surface of the card for extra security.

Altogether, the system delivers a robust one-pass solution for secure card issuance, combining printing, laser engraving and optional lamination (via accessory module) in a workflow-friendly format.

✅ Key Features

• High-resolution colour retransfer printing (600 × 600 dpi) ensures sharp graphics and over-edge coverage.

• Fibre-laser engraving module (10 W MOPA fibre laser) with high-definition duplex marking (up to 1200 dpi) for security features. Matica+1

• Dual-sided (duplex) output standard, enabling printing and engraving on both sides of the card in one pass.

• High throughput: up to ~120 cards per hour (varies by configuration) in colour printing + laser engraving mode.

• Support for invisible UV colour printing simultaneously with visible colours for added security.

• Large card input/output hopper capacity (up to 250-card input and 250-card output) for efficient batch processing.

• Works with multiple card materials: PC, PET, PET-F/G, ABS; card thickness from 0.25 mm to 1.0 mm (10–40 mil) depending on configuration.

• Interface & connectivity: Ethernet, USB (1.0/2.0/3.0), RS-232C serial.

• Optional inline lamination module (MC-L) and additional security modules (barcode/2D reader, OCR camera) for full issuance workflow.

✅ Why Buy This Product

• If your organisation issues secure identity cards, access credentials or membership cards that demand high durability, sophisticated anti-counterfeiting features and professional-quality appearance, the LCP9660 is a top-tier option.

• The combination of full-colour retransfer printing plus laser engraving means you get both aesthetic output and embedded security features in one pass — reducing workflow complexity.

• Its high throughput and large card hopper capacity make it suitable for programs issuing hundreds or thousands of cards per day, not just low-volume office uses.

• The modular design (with optional lamination and encoding upgrades) gives flexibility to scale or add functionality (smart-card encoding, mag-stripe, contactless) as your needs evolve.

• For decentralised issuance scenarios (e.g., regional branches, satellite sites) the simplicity and combined workflow minimise training and maintenance demands.

• For markets like Bangladesh and elsewhere where durability, anti-fraud features and future-proofing matter, this system offers an investment that goes beyond typical desktop card printers.
