ONV H3024PF 26 Port Full Gigabit SFP PoE Fiber Switch

Buy ONV H3024PF 26 Port Full Gigabit SFP PoE Fiber switch Price in Bangladesh.

The ONV-H3024PF is an advanced 26-port Full Gigabit SFP PoE Fiber switch, designed to deliver high-performance networking solutions. It features 24 fixed ports supporting 10/100/1000Base-T with PoE capability, providing both data and power to connected devices. Additionally, it includes 2 1000Base-X uplink SFP ports for high-speed data connectivity. The Ethernet ports (1-24) support 10/100/1000Base-T auto-sensing with full/half duplex MDI/MDI-X self-adaptation. Twisted pair transmission accommodates various cable types, including Cat3, Cat4, Cat5 UTP for 10BASE-T, Cat5 or later UTP for 100BASE-TX, and Cat5e or later UTP for 1000BASE-T within a range of ≤100 meters. For fiber connectivity, the switch is equipped with 2 Gigabit SFP optical fiber interfaces, supporting optional single-mode/multi-mode, single fiber/dual fiber optical modules with LC connectors. The optical cable distance varies, with multi-mode covering 0-500m, and single-mode featuring 1310nm/0-40km and 1550nm/0-120km. In terms of chip parameters, the switch adheres to IEEE802.3 standards, including 10BASE-T, 10Base-T, 100Base-TX, 1000Base-T, 1000Base-X, and IEEE802.3x. It operates in a Store and Forward mode at full wire speed, boasting a non-blocking 52Gbps switching capacity, a forwarding rate of 38.69Mpps at a 64-byte packet size, an 8K MAC table, 4M buffer memory, and supports Jumbo Frames up to 10K. The LED indicators provide clear visual status updates, including Power (PWR, Green), Network Link (Green), PoE (Green), Fiber G1/G2 (Green), and PoE (Green). In terms of Power over Ethernet (PoE) and power supply, ports 1 to 24 support IEEE802.3af/at standards, each with a maximum power of 30W. The switch is capable of delivering a total power of 250W, with a power supply pin configuration of default 1/2(+) 3/6(-). Power consumption varies from 20W in standby mode to 250W at full load. The built-in power adapter operates on AC 100~240V at 50-60Hz with a current of 4.1A. Physically, the switch is designed to operate in temperatures ranging from -20~+55°C with a humidity range of 5%90% RH (Non-condensing). For storage, it is suitable for temperatures between -40+75°C with a humidity range of 5%~95% RH (Non-condensing). The dimensions measure 33020444mm, with a net weight of <3.0kg and a gross weight of <3.5kg. The switch is versatile in installation, suitable for desktop, wall-mounted, and 19-inch 1U cabinet setups. Certifications include CCC, CE mark, commercial, CE/LVD EN62368-1, FCC Part 15 Class B, and RoHS compliance. The switch comes with a 1-year warranty, and lifelong maintenance support, featuring lightning protection at 4KV 8/20us and a protection level of IP30.
