Zebra ZD510-HC Wristband 300dpi Barcode Label Printer

Cash Price: ৳89,500.00 Regular Price:৳97,500.00
Availability: In Stock SKU: 1.10.19.3480
Quick Overview
Brand:
ZEBRA
Model:
ZD510-HC
  • Resolution: 300 DPI
  • Printing Method: Direct Thermal
  • Max. Print Speed: 120 mm/Secend
  • Interface (Built-in): USB, LAN, Wi-Fi, Bluetooth
  • Consumable: Zebra 1 x 10inch Z-Band Wristband Ribbon
  • Used: Hospitals, Healthcare, Amusement Parks and Hospitality Venues

View More
Rating: (0 Reviews)

Payment Options
Share:
  • Support

    Saturday – Thursday: 09 AM - 06 PM.
  • Hotline

    0967 881 4452
  • Whatsapp

    +880170 999 8397
  • Payment

    Cash on Delivery | Card | Online Payment
  • Shipping Cost

    Inside Dhaka 350tk | Outside Dhaka 450tk
  • Warranty Policy

    Read More

Specification

General Information
Band Zebra
Model ZD510-HC
Type Barcode Label Printer
Technical Info
Cutter Unmentioned
Resolution 300 dpi
Print Performance
Printing Method Direct Thermal
Max. Print Speed 120 mm/sec
Direct Printing Yes
Paper Information
Tape Size Unmentioned
Maximum Tape Width Unmentioned
Storage & Interface
Memory Type SDRAM
Memory 16MB
Storage Type Flash
Storage 8MB 8MB
Interface (Built-in) USB, LAN, Wi-Fi, Bluetooth
Interface (Optional) Wi-Fi
Main Features
Font Styles 16 resident expandable bitmap fonts
Mirror Printing Yes
Bar-codes Types 2D Barcodes: PDF417, MicroPDF-417, Code 49, Maxicode, Codablock, Data Matrix, QR code, and Aztec
Software
Printer Language ZPL & ZPL II
Power
Power Consumption 100-240VAC, 50-60Hz (70Watt)
Operating Temperature 32 Degree C - 104 degree C
Operating Humidity 20% to 85%, non-condensing
Storing/Storage Temperature -40 degree C - 140 degree C
Storing/Storage Humidity 5% to 85%, non-condensing
Physical Description
Color White & Gray
Dimensions 242 x 127 x 178mm
Weight (Kg) 1.4 Kg
Consumable Zebra 1 x 10inch Z-Band Splash Wristband Direct thermal Ribbon (350/roll,6/box) #10012717-6K
Color Ribbon Supported No
Others info
Others Connectivity: USB 2.0, USB Host, Bluetooth Low Energy, 10/100 Ethernet.
Country Of Origin USA
Made in/ Assemble China
Warranty
Warranty Details 1 Year Service (Without Adapter)

Description

The Zebra ZD510-HC is a specialized monochrome direct thermal wristband barcode printer designed for healthcare and other industries that require durable and reliable wristband printing solutions. Zebra ZD510-HC Mono 300dpi Direct Thermal USB LAN BT Wristband Barcode Printer has A Wristband Printer That Specializes in Healthcare. The ZD510-HC wristband printing solution combines the reliable ZD510-HC direct thermal printer with easy-to-load cartridges containing the only antimicrobial-coated wristbands on the market─Zebra's Z-Band wristbands. Also capable of printing wristbands for amusement, water park and entertainment applications, you get dependable wristband printing that increases patient safety and staff productivity. It excels in settings like hospitals, healthcare facilities, amusement parks, and hospitality venues where patient or guest identification is crucial. Below is an in-depth breakdown of its features, capabilities, and use cases.

Printer Type & Functionality

  • Printer Type: Direct thermal wristband printer.
    • Direct Thermal Technology: Unlike traditional printers that use ink or toner, direct thermal printers use heat-sensitive paper or wristbands. This technology is ideal for creating high-quality, durable barcodes and text without the need for ink, ribbons, or toner, which reduces maintenance costs and downtime.
  • Monochrome Output: The ZD510-HC prints in black and white only, specifically for text, barcodes, and basic graphics.
  • Functionality: The primary purpose of this printer is to produce wristband labels for patient identification, guest management, and event entry tracking. It is designed for high-demand environments where fast, reliable printing is needed.

Targeted Use Cases

  • Healthcare: Ideal for hospital and healthcare settings where patient identification is critical. It supports wristbands that are easy to read and durable enough to withstand daily hospital activities, including exposure to water, sanitizers, and various chemicals.
  • Hospitality and Amusement Parks: Perfect for printing wristbands for guest management, ticketing, and entry control. The durable wristbands can handle rough conditions like water parks, and high-throughput environments like concerts or theme parks.
  • Events and Venues: Helps in printing wristbands that can track visitor entry, maintain security, and manage guest identification in high-volume settings.

Key Features

  • 300 dpi Print Resolution: With a 300 dpi (dots per inch) print resolution, the Zebra ZD510-HC produces highly detailed wristbands, ensuring that barcodes, text, and graphics are sharp and scannable. This resolution is particularly important for healthcare applications where patient wristbands need to be easily readable by both humans and scanners.

Connectivity Options

The Zebra ZD510-HC is equipped with a wide array of connectivity options, making it highly versatile for integration into various workflows:

  • USB: Provides a direct connection to a local PC or laptop.
  • LAN (Ethernet): Allows for networked printing, making it easy to share the printer across multiple workstations or integrate it into a hospital or business network. This is particularly useful for environments with multiple users needing access to the printer.
  • Bluetooth (BT): Enables wireless printing from Bluetooth-enabled devices like smartphones, tablets, or laptops. This is handy for mobile printing setups, especially in healthcare environments where mobility is important.

Ease of Use

  • Zebra Wristband Cartridge System: One of the standout features of the Zebra ZD510-HC is its easy-to-load wristband cartridge system. This cartridge system ensures that even non-technical users can load and change wristband supplies quickly, minimizing downtime and maximizing productivity.
  • Healthcare-Grade Materials: The printer is designed with healthcare environments in mind, built with materials that can withstand frequent cleanings with harsh disinfectants, ensuring the device meets stringent healthcare standards for sanitation and hygiene.

Wristband Support

The ZD510-HC is compatible with Zebra's Z-Band wristbands, which are available in a variety of sizes, colors, and designs to suit different applications:

  • Z-Band Direct: These are soft, flexible wristbands that are comfortable to wear and durable enough to withstand the demands of healthcare settings.
  • Z-Band Fun: Designed for amusement parks and entertainment venues, these wristbands are durable and can handle exposure to water and rough conditions.

Durability & Reliability

  • Long-Lasting Durability: The direct thermal technology used by the ZD510-HC ensures that the printed wristbands are resistant to smudging, fading, and exposure to moisture. This is especially critical in environments like hospitals where wristbands may be exposed to water or sanitizing agents.
  • Built for Continuous Use: The printer is designed to handle high-volume printing with minimal maintenance, making it reliable for environments with heavy wristband printing demands, such as hospitals or event venues.

Software & Integration

  • Zebra Print DNA Software Suite: The printer comes equipped with Zebra’s Print DNA suite of software tools, which helps enhance management, deployment, and troubleshooting. This software simplifies integration into existing systems, whether in healthcare or entertainment environments, and ensures smooth operation and easy updates.
  • EMR Integration: In healthcare settings, the ZD510-HC is compatible with many Electronic Medical Record (EMR) systems, ensuring that patient information is accurately printed on wristbands without the need for manual data entry, reducing errors.

Environmental Considerations

  • Disinfectant-Ready: Given the demands of healthcare settings, the ZD510-HC is designed to be wiped down with disinfectant frequently, helping to maintain a clean and sterile environment.
  • Compact and Mobile-Friendly: Its small size makes it easy to move around as needed, ideal for healthcare stations or mobile check-in kiosks in amusement parks or events.

Print Speed

  • The printer is capable of fast print speeds, ensuring that high volumes of wristbands can be printed quickly during peak times, whether it’s for patient admissions or event guest management.

Power and Energy Efficiency

  • Power-Efficient: The ZD510-HC is designed to be power-efficient, which is particularly beneficial in environments that require continuous operation. It consumes minimal power when not in use, reducing overall operating costs.

Dimensions & Weight

  • The Zebra ZD510-HC is compact, lightweight, and easy to fit into various workspace configurations. Exact dimensions may vary slightly depending on the wristband cartridge loaded.

What’s Included

When you purchase the Zebra ZD510-HC, you typically get the following components:

  • The ZD510-HC printer unit.
  • Power supply and cords.
  • A starter cartridge of Zebra Z-Band wristbands.
  • User documentation for easy setup and operation.

Warranty

Zebra typically offers a 1-year limited warranty on the printer. Extended warranty and service options are also available to ensure long-term protection and support, especially in critical environments like healthcare.

Conclusion

The Zebra ZD510-HC Mono 300dpi Direct Thermal USB LAN BT Wristband Barcode Printer is an industry-leading solution for wristband printing, offering high-resolution, fast, and durable output for healthcare, entertainment, and hospitality sectors. Its direct thermal technology ensures low maintenance, while its healthcare-ready design and multiple connectivity options make it versatile and reliable for high-demand environments. Whether you are managing patient admissions or overseeing guest entry at a theme park, the Zebra ZD510-HC delivers accuracy, durability, and efficiency.

What is the price of Zebra ZD510-HC Wristband 300dpi Barcode Label Printer in Bangladesh?

The latest price of Zebra ZD510-HC Wristband 300dpi Barcode Label Printer in Bangladesh is ৳89,500.00 . You can buy the Zebra ZD510-HC Wristband 300dpi Barcode Label Printer at best price from BME ONLINE SHOP, Bangladesh.
